| K-cell Series | ||
| Standard type(THKC Series) | ||
 |
Specifications
 Maximum temperature : 1300℃ Heater: Top heat or standard heat type Crucible material: PBN Source capacity: 10cc～200cc |
|
| High Temperature K-cell (THKC-1300HI THKC-1900HI) | ||
 |
Specifications
 Maximum temperature : 1500℃
Heater: Top heat type Crucible material: Alimina(4N) Source capacity: 10cc, 25cc |
|
|
Si K-cell(THKC-1000-HI) |
||
 |
Specifications
 Maximum temperature : 1600℃ Heater: Top heat type Crucible material: Special type Source capacity: 4cc
|
|
|
Super Small K-cell(KC-1300-S)
|
||
 |
Specifications Maximum temperature : 1300℃ Crucible material: PBN Source capacity: 2cc |
|
|
Dual K-cell(DSGC-1400SH)
|
||
 |
Specifications Maximum temperature : 1300℃ (Solid Cell)Crucible material: PBN Source capacity: 6cc |
|
| ECR Radical Cell (RC-1400AE) | ||
 |
Specifications Plasma-enhance: ECR 2.45GHz Ion removal system Crucible material: BN Power supply: 10W～100W |
|
 |
||
